Building a Production Observability Stack with Prometheus and Grafana

Beyond Basic Monitoring

There is a meaningful difference between monitoring and observability. Monitoring tells you when something is wrong. Observability tells you why. A production-grade observability stack combines metrics, logs, and traces into a unified view that lets your team diagnose issues in minutes instead of hours.

In this guide, we walk through the stack we deploy most frequently at DevOpsVibe: Prometheus for metrics, Grafana for visualization, Alertmanager for notifications, and Loki for log aggregation. All running on Kubernetes.

Architecture Overview

The stack consists of four primary components:

• Prometheus -- scrapes and stores time-series metrics from your services and infrastructure
• Grafana -- provides dashboards, exploration tools, and a unified query interface
• Alertmanager -- handles alert routing, deduplication, grouping, and silencing
• Loki -- a horizontally-scalable log aggregation system designed to work with Grafana

Together, these tools give you the three pillars of observability: metrics, logs, and (with the addition of Tempo) traces.

Deploying the Stack with Helm

The fastest path to production is the kube-prometheus-stack Helm chart, which bundles Prometheus, Grafana, Alertmanager, and a set of preconfigured recording rules and dashboards:

helm repo add prometheus-community https://prometheus-community.github.io/helm-charts
helm repo update

helm install monitoring prometheus-community/kube-prometheus-stack \
  --namespace monitoring \
  --create-namespace \
  --values custom-values.yaml

Custom Values

Here is a production-tuned custom-values.yaml:

# custom-values.yaml
prometheus:
  prometheusSpec:
    retention: 30d
    retentionSize: "50GB"
    storageSpec:
      volumeClaimTemplate:
        spec:
          storageClassName: gp3
          accessModes: ["ReadWriteOnce"]
          resources:
            requests:
              storage: 100Gi
    resources:
      requests:
        memory: 4Gi
        cpu: "2"
      limits:
        memory: 8Gi
    scrapeInterval: 30s
    evaluationInterval: 30s

grafana:
  adminPassword: "${GRAFANA_ADMIN_PASSWORD}"
  persistence:
    enabled: true
    size: 10Gi
  dashboardProviders:
    dashboardproviders.yaml:
      apiVersion: 1
      providers:
        - name: custom
          orgId: 1
          folder: "Custom"
          type: file
          disableDeletion: false
          editable: true
          options:
            path: /var/lib/grafana/dashboards/custom

alertmanager:
  alertmanagerSpec:
    storage:
      volumeClaimTemplate:
        spec:
          storageClassName: gp3
          accessModes: ["ReadWriteOnce"]
          resources:
            requests:
              storage: 5Gi

Configuring Service Discovery

Prometheus automatically discovers targets in Kubernetes using ServiceMonitor and PodMonitor custom resources. To monitor a new application, create a ServiceMonitor:

# servicemonitor.yaml
apiVersion: monitoring.coreos.com/v1
kind: ServiceMonitor
metadata:
  name: my-api
  namespace: monitoring
  labels:
    release: monitoring
spec:
  selector:
    matchLabels:
      app: my-api
  namespaceSelector:
    matchNames:
      - production
  endpoints:
    - port: metrics
      interval: 15s
      path: /metrics
      scrapeTimeout: 10s

The key detail many teams miss: the release: monitoring label must match the Helm release name. Without it, Prometheus will not pick up your ServiceMonitor.

Building Effective Dashboards

A common mistake is creating dashboards with dozens of panels that no one looks at. Instead, follow the RED and USE methods:

The RED Method (for services)

• Rate -- requests per second
• Errors -- error rate as a percentage
• Duration -- latency percentiles (p50, p95, p99)

The USE Method (for resources)

• Utilization -- percentage of resource capacity in use
• Saturation -- amount of work queued
• Errors -- count of error events

Here is a Grafana dashboard panel definition for API latency using PromQL:

{
  "title": "API Latency (p99)",
  "type": "timeseries",
  "targets": [
    {
      "expr": "histogram_quantile(0.99, sum(rate(http_request_duration_seconds_bucket{service=\"my-api\"}[5m])) by (le))",
      "legendFormat": "p99"
    },
    {
      "expr": "histogram_quantile(0.95, sum(rate(http_request_duration_seconds_bucket{service=\"my-api\"}[5m])) by (le))",
      "legendFormat": "p95"
    },
    {
      "expr": "histogram_quantile(0.50, sum(rate(http_request_duration_seconds_bucket{service=\"my-api\"}[5m])) by (le))",
      "legendFormat": "p50"
    }
  ]
}

Alerting That Does Not Cause Fatigue

Alert fatigue is the number one reason monitoring investments fail. Engineers start ignoring alerts, and then a real incident goes unnoticed. Here is how we configure Alertmanager to prevent that:

# alertmanager-config.yaml
global:
  resolve_timeout: 5m
  slack_api_url: "${SLACK_WEBHOOK_URL}"

route:
  receiver: "default"
  group_by: ["alertname", "namespace", "service"]
  group_wait: 30s
  group_interval: 5m
  repeat_interval: 4h
  routes:
    - match:
        severity: critical
      receiver: "pagerduty-critical"
      repeat_interval: 15m
    - match:
        severity: warning
      receiver: "slack-warnings"
      repeat_interval: 4h

receivers:
  - name: "default"
    slack_configs:
      - channel: "#alerts-default"
        title: '{{ .GroupLabels.alertname }}'
        text: '{{ range .Alerts }}{{ .Annotations.description }}{{ end }}'

  - name: "pagerduty-critical"
    pagerduty_configs:
      - service_key: "${PAGERDUTY_SERVICE_KEY}"
        severity: critical

  - name: "slack-warnings"
    slack_configs:
      - channel: "#alerts-warnings"

inhibit_rules:
  - source_match:
      severity: critical
    target_match:
      severity: warning
    equal: ["alertname", "namespace"]

Writing Good Alert Rules

Every alert should be actionable. If an engineer receives an alert and does not know what to do, the alert should not exist.

# alert-rules.yaml
apiVersion: monitoring.coreos.com/v1
kind: PrometheusRule
metadata:
  name: api-alerts
  namespace: monitoring
spec:
  groups:
    - name: api.rules
      rules:
        - alert: HighErrorRate
          expr: |
            sum(rate(http_requests_total{status=~"5.."}[5m])) by (service)
            /
            sum(rate(http_requests_total[5m])) by (service)
            > 0.05
          for: 5m
          labels:
            severity: critical
          annotations:
            summary: "High error rate on {{ $labels.service }}"
            description: "{{ $labels.service }} is returning 5xx errors at {{ $value | humanizePercentage }} over the last 5 minutes."
            runbook: "https://wiki.example.com/runbooks/high-error-rate"

        - alert: HighLatency
          expr: |
            histogram_quantile(0.99, sum(rate(http_request_duration_seconds_bucket[5m])) by (le, service))
            > 2.0
          for: 10m
          labels:
            severity: warning
          annotations:
            summary: "High p99 latency on {{ $labels.service }}"
            description: "p99 latency for {{ $labels.service }} is {{ $value }}s, exceeding 2s threshold."

Adding Log Aggregation with Loki

Deploy Loki alongside your Prometheus stack to unify metrics and logs in Grafana:

helm install loki grafana/loki-stack \
  --namespace monitoring \
  --set promtail.enabled=true \
  --set loki.persistence.enabled=true \
  --set loki.persistence.size=50Gi \
  --set loki.persistence.storageClassName=gp3

Then add Loki as a data source in Grafana. The power of this setup is the ability to jump from a metric spike directly to the corresponding logs using Grafana's split view and label matching.

A typical LogQL query to find errors:

{namespace="production", app="my-api"} |= "error" | json | level="error" | line_format "{{.timestamp}} {{.message}}"

SLO-Based Monitoring

Rather than alerting on arbitrary thresholds, define Service Level Objectives and alert on burn rates:

• SLI: The ratio of successful requests to total requests
• SLO: 99.9% of requests should succeed over a 30-day window
• Error budget: 0.1% of requests can fail (approximately 43 minutes of downtime per month)

Alert when your error budget is burning too fast:

- alert: ErrorBudgetBurnRate
  expr: |
    (
      sum(rate(http_requests_total{status=~"5.."}[1h])) by (service)
      /
      sum(rate(http_requests_total[1h])) by (service)
    ) > (14.4 * 0.001)
  for: 5m
  labels:
    severity: critical
  annotations:
    summary: "Error budget burning fast for {{ $labels.service }}"

Operational Tips

• Right-size your retention. 30 days of high-resolution data with downsampled long-term storage via Thanos or Cortex.
• Use recording rules to precompute expensive queries. This dramatically improves dashboard load times.
• Separate alerting Prometheus from dashboarding Prometheus in large environments to avoid query load affecting alert evaluation.
• Store dashboards as code in version control using Grafana's provisioning system or tools like Grafonnet.
• Test your alerts. Use promtool to unit test alert rules before deploying them.

Conclusion

A well-built observability stack is not a luxury -- it is the foundation that makes everything else possible. Without it, incident response is guesswork, capacity planning is a gamble, and performance optimization is shooting in the dark.
